4 axis cnc milling machine cnc router 1325 price cnc machine price cnc insert 4 axis cnc sale in dubai
Original price was: 8,712.00€.6,776.00€Current price is: 6,776.00€. exc. 19% Vat
- 14 days Return and Refund - check our Return and Refund Policy
- Shipping Time: 7 - 10 Business Days Worldwide - check out our Shipping Policy
- Payment Options: Bank Transfer and Crypto
- For Questions: use our Livechat or Contact us Form
- Is Smart Device: YES
- Model Number: TEM1325
- Condition: New
- Brand Name: TEKAI
- CNC or Not: CNC
- product name: TEM1325
- colour: black
- Spindle: 3.0kw water cooling spindle
- Transmission in X, Y axis: Transmission in X, Y axis
- Motor: Stepper motor
- Driver: Leadshine driver
- Engraving speed: 38000mm/min
- Cutting speed: 25000mm/min
- Working precision: 0.01mm
- power: 4.5kw
- Colour: can be customerized
4 axis cnc milling machine cnc router 1325 price cnc machine price cnc insert 4 axis cnc sale in dubai
Technical features
1 Thicker square tube bed makes the operation more stable and accuracy. 2 Our machines adopt the vacuum or T-slot dual-use table, you can use the clips to fix the small-scale materials, which can save the vacuum pump electricity, and you can adopt the vacuum adsorption to fix large-scale material.so the processing is convenient, simple and efficient. 3 High quality Taiwan imported Linear guide has much longer life 10 times of life-time than round guide; It is stable and hard to distort. 4 3KW top brand water cooling spindlehas much powerful strength; So for processing your softmetal it will have higher efficiency.It will have a better effect . 5 the Mach3 control system is a very popular control system with high quality. Its with USB port. 6 Double motor for Y axis make the cnc machine work with more strength
|
Model |
TEM1325 |
|
|
Working Area |
1300x2500mm |
|
|
Working Table |
T-slot |
|
|
Framework |
Cast Iron body |
|
|
Spindle Motor |
3.0kw water cooling spindle |
|
|
Rotating Speed |
2,4000RPM |
|
|
Working Mode |
Stepper |
|
|
Guide Rails |
linear guide rail |
|
|
Drive Mechanism |
ball screw transmission |
|
|
Repositioning Accuracy |
± 0.03mm |
|
|
Max Motion Speed |
38,000mm/min |
|
|
Max Engraving Speed |
25,000mm/min |
|
|
Dictate Formate |
G code,*uoo,*mmg,*plt |
|
|
Interface |
parallel |
|
|
Operating Voltage |
AC220V/380V 50/60HZ |
|
|
Control System |
Mach3 Control System |
|
|
Support Software |
UCanCAM /Type3/ArtCAM for optional |
|
|
Net Weight |
1300KGS |
|
|
Gross Weight |
1500KGS |
|
|
Packing Size |
3140*2170*1840mm |
|
|
Packaging |
Standard Plywood Case for Export |
|
|
Delivery Time |
7-15 Working Days |
|
|
Payment Terms |
T/T |
Detailed parts:
Certificate
FAQ
1) This is the first time I use this kind of machine, is it easy operate?
There are English manual or guide video that show how to use machine.
If there is still have any question, we can talk from phone or Skype.
2)Can you recommend a CNC ROUTER MACHINE to me,thanks?
Yes, In order to give you a suitable router machine, please tell me the max working
area, materials for processing and the thickness for materials processing engraving
or cutting. Then perfect suitable CNC router will be recommended.
3) If machine have any problem after I ordered it, how could I do?
Free parts send to you in machine warranty period if machine have any problem.
Free after-sales service life for machine, please feel free contact us if your machine have any problem.
we will give you 24hours service from phone and Skype.
